The cleaning system of the Fendt IDEAL 9 has been reworked, helping to boost the machine's overall performance even further, with improved cleaning results. In the new cleaning system, the grain drops down to the top sieve through two curved double-drop steps. Thanks to the curved shape, the laws of physics see the heavy grains gather in the lower section while the lighter parts accumulate above.
The curved steps of the cleaning system provide a wider air outlet, which can significantly increase the air volume and make the cleaning process even more efficient. With two drop levels, most of the short straw and chaff is separated on the first level. The remaining non-grain components are separated on the second. The cleaning system works over four sections, two return floors ensure even distribution and coverage across the preparation floor.
The ActiveSpread SwingFlow straw distributor has been specially designed for tough harvesting conditions. ActiveSpread SwingFlow is an extra straw spreading option that achieves a more even distribution even in humid harvest conditions.
